Form & Dimensions

Technical documentation with precise measurements and dimensional clarity. All dimensions are provided in millimeters, following international standards.

Studio Series Dimensions

Studio series technical drawing front elevation 800mm 450mm

Base dimensions: 450mm × 300mm. Maximum height: 800mm. Adjustable angle range: 15° to 85°. Weight: 2.8kg.

Minimal Series Dimensions

Minimal series technical drawing side view 500mm 350mm

Base dimensions: 350mm × 250mm. Display height: 500mm. Fixed angle: 75°. Weight: 1.5kg.

Technical Series Dimensions

Technical series technical drawing with measurement grid 900mm 500mm 400mm

Base dimensions: 500mm × 400mm. Maximum height: 900mm. Adjustable angle range: 0° to 90° with 5° increments. Weight: 4.2kg. Includes integrated measurement scale with 10mm graduations.

Material Specifications

Material thickness and density specifications
Hardware specifications and tolerances
Finish and surface treatment details

All components are manufactured to ISO 9001 standards. Primary materials: European beech wood (Fagus sylvatica), brass hardware (CuZn37), and precision-machined steel components. Surface finishes: natural oil, matte lacquer, or raw finish options available.

Assembly & Adjustment

Assembly diagram showing component relationships
Adjustment mechanism technical detail
Hardware installation specifications

All objects are supplied with detailed assembly instructions. Adjustment mechanisms use precision-machined components with tolerances of ±0.1mm. No specialized tools required for assembly or adjustment.
